Mastering the Pedal Wrench: A Comprehensive Guide to Pedal Installation and Removal

Bicycle pedals, seemingly simple components, play a crucial role in transmitting your power to the drivetrain. Correctly installing and removing them is essential for both performance and safety. While seemingly straightforward, dealing with pedals often presents challenges due to tight threads, incorrect technique, and potential damage. This guide provides an in-depth look at using a pedal wrench effectively, covering everything from choosing the right tool to troubleshooting common issues.

Understanding Pedal Threads and Orientation

Before even thinking about wrenching, understanding the crucial difference between left and right pedals is paramount. Pedals are threaded differently to prevent them from loosening during riding. This seemingly simple design feature dictates the direction you'll need to turn the wrench for both installation and removal.

• Right Pedal (Drive-Side): This pedal has a standard right-hand thread. This means you tighten it by turning it clockwise (as viewed from the end of the crank arm) and loosen it by turning it counter-clockwise.
• Left Pedal (Non-Drive-Side): This pedal has a left-hand thread. This is the critical difference! You tighten it by turning it counter-clockwise (as viewed from the end of the crank arm) and loosen it by turning it clockwise.

Many pedals are marked with an "L" for left or an "R" for right, either on the pedal axle itself or on the end cap. Always double-check before attempting to install or remove a pedal. Failure to do so will likely result in damaged threads, making the repair significantly more difficult and expensive.
Important: Forcing a pedal in the wrong direction can permanently damage the crank arm threads. This often necessitates replacing the entire crankset, a costly repair. Always double-check the thread direction before applying significant force.

Choosing the Right Pedal Wrench

While other tools can be used in a pinch (like a large adjustable wrench), a dedicated pedal wrench is the best tool for the job. Here's why:

• Thickness: Pedal wrenches are typically thinner than standard wrenches. This slim profile allows them to fit between the pedal body and the crank arm without damaging either component. Standard wrenches are often too thick and can mar the crank arm's finish.
• Length: Pedal wrenches are generally longer than standard wrenches. This added length provides increased leverage, making it easier to break free stubborn pedals. This is especially important when dealing with older pedals that may have become seized over time.
• Open End: Pedal wrenches almost always have an open-end design, precisely sized (usually 15mm) to fit the flats on the pedal axle. Some also include an Allen wrench socket (usually 6mm or 8mm) on the opposite end, allowing you to remove pedals that use an Allen key interface.
• Durability: Quality pedal wrenches are made from hardened steel, capable of withstanding the high torque required for pedal removal.

When choosing a pedal wrench, look for the following:

• Material: Opt for a wrench made from chrome vanadium steel or a similar high-strength alloy.
• Length: A longer wrench (around 12-15 inches) provides better leverage.
• Grip: A comfortable and ergonomic handle will make the job easier and reduce the risk of hand fatigue.
• Dual Functionality (Optional): Some pedal wrenches include both a 15mm open-end and an Allen key socket, offering versatility for different pedal types.

Investing in a good quality pedal wrench will save you headaches and prevent damage to your bike in the long run. Cheap, poorly made wrenches can slip and damage the pedal or crank arm.

Preparing for Pedal Installation and Removal

Before you start wrenching, take the time to prepare your workspace and the components. This will make the process smoother and reduce the risk of errors.

1. Cleanliness is Key: Clean the pedal threads and the crank arm threads thoroughly. Use a degreaser and a brush to remove any dirt, grease, or debris. A clean surface allows for proper lubrication and prevents contaminants from damaging the threads.
2. Lubrication: Apply a generous amount of grease to the pedal threads. Marine grease or anti-seize compound are excellent choices. This lubrication is crucial for preventing the pedals from seizing in the crank arms over time, making future removal much easier. It also helps prevent galvanic corrosion, especially when using pedals with steel axles in aluminum cranks.
3. Bike Positioning: Secure the bike in a repair stand or lean it against a stable surface. The bike needs to be stable so you can apply force to the wrench without the bike moving or tipping over. Having the bike at a comfortable working height will also reduce strain on your back.
4. Proper Lighting: Ensure you have adequate lighting to clearly see the pedal threads and the wrench engagement.
5. Gloves (Optional): Wearing gloves can protect your hands from grease and sharp edges.

Pedal Removal: A Step-by-Step Guide

Removing pedals, especially those that have been installed for a long time, can be challenging. Here's a detailed breakdown of the process:

1. Identify Pedal Type: Determine if your pedals use a 15mm wrench flat or an Allen key socket on the axle.
2. Position the Wrench:
   • Wrench Flat: Position the pedal wrench on the 15mm wrench flat of the pedal axle. Ensure the wrench is fully engaged and seated properly.
   • Allen Key: Insert the appropriate size Allen key into the socket on the pedal axle.
3. Applying Force (The Crucial Part): This is where understanding thread direction is critical!
   • Right Pedal (Drive-Side): Place the wrench in the 9 o'clock position and push downwards towards the ground. This is because you need to turn the wrench counter-clockwise to loosen the right pedal.
   • Left Pedal (Non-Drive-Side): Place the wrench in the 3 o'clock position and push downwards towards the ground. This is because you need to turn the wrench clockwise to loosen the left pedal.
   • Using Allen Key: With the Allen key fully inserted, turn the key toward the rear of the bike on both sides to loosen the pedal. Remember left is still reverse thread!
4. Leverage and Persistence: If the pedal is stuck, apply steady, consistent pressure. Avoid jerking the wrench, as this can increase the risk of slippage and damage.
   • Increased Leverage: If needed, use a cheater bar (a length of pipe) to extend the wrench handle and increase leverage.
   • Heat (Use with Caution): In extreme cases, applying heat to the crank arm (around the pedal axle) can help loosen the threads. Use a heat gun or hair dryer, and be careful not to overheat the aluminum crank arm, as this can weaken it. Avoid using a torch, as the high heat can damage the crank arm's temper.
   • Penetrating Oil: Apply a penetrating oil (like PB Blaster or Liquid Wrench) to the pedal threads and let it soak for several hours or even overnight. This can help break down corrosion and loosen the bond between the pedal and the crank arm.
5. Loosening the Pedal: Once the pedal starts to loosen, continue turning the wrench in the correct direction until the pedal is completely unthreaded.
6. Repeat for the Other Pedal: Follow the same steps for the other pedal, remembering to reverse the direction due to the left-hand thread on the non-drive side.

For extremely stubborn pedals, try tapping the end of the wrench with a rubber mallet. The vibration can help break the bond between the threads.

Pedal Installation: A Step-by-Step Guide

Installing pedals correctly is just as important as removing them. Here's how to do it properly:

1. Grease the Threads: Apply a generous amount of grease to the pedal threads. This will prevent them from seizing and make future removal easier.
2. Start by Hand: Carefully thread the pedals into the crank arms by hand. Ensure the pedal is aligned properly and that the threads engage smoothly. Never force the pedal! If it feels tight or cross-threaded, stop immediately and realign the pedal.
3. Tighten with the Wrench:
   • Right Pedal (Drive-Side): Place the wrench on the 15mm wrench flat (or insert the Allen key) and tighten the pedal by turning it clockwise (as viewed from the end of the crank arm).
   • Left Pedal (Non-Drive-Side): Place the wrench on the 15mm wrench flat (or insert the Allen key) and tighten the pedal by turning it counter-clockwise (as viewed from the end of the crank arm).
4. Tightening Torque: Tighten the pedals to the manufacturer's recommended torque specification. This is typically around 30-40 Nm (22-30 ft-lbs). If you don't have a torque wrench, tighten the pedals firmly but do not over-tighten them. Over-tightening can damage the threads.
5. Final Check: Double-check that both pedals are securely tightened and that they rotate freely.

A torque wrench is a worthwhile investment for any serious cyclist. It allows you to tighten components to the precise specifications, preventing both under-tightening (which can lead to loosening) and over-tightening (which can damage components).

Troubleshooting Common Pedal Problems

Even with careful preparation and the right tools, you may encounter issues during pedal installation and removal. Here are some common problems and how to address them:

• Stripped Threads: This is a serious problem that can occur if you force a pedal in the wrong direction or over-tighten it.
  • Minor Damage: If the damage is minor, you may be able to clean up the threads with a thread chaser or a tap and die set.
  • Significant Damage: If the threads are severely damaged, you may need to have the crank arm professionally repaired or replaced. One option is to use a thread repair kit (e.g., Heli-Coil) to insert new threads. However, this requires specialized tools and skills. Replacing the crankarm may be the easier and safer solution.
• Stuck Pedals: As mentioned earlier, applying heat, penetrating oil, and increased leverage can often help loosen stuck pedals. Patience is key.
• Pedal Squeak: A squeaking pedal can be annoying and is often caused by dry threads. Remove the pedal, clean and grease the threads, and reinstall it. Also check the pedal bearings themselves, as they may need lubrication or replacement.
• Pedal Wobble: A wobbly pedal can indicate loose threads, damaged bearings, or a bent pedal axle. Inspect the pedal and crank arm for damage and tighten the pedal securely. If the problem persists, the pedal may need to be replaced.
• Difficulty Engaging the Wrench: If the pedal wrench doesn't fit properly, double-check that you are using the correct size wrench (15mm is the most common). Ensure that the wrench is fully seated on the wrench flat. If the wrench flat is damaged, you may need to use a different tool (like a vise grips, with extreme caution) or replace the pedal.

Pedal Maintenance: Preventing Future Problems

Regular maintenance can prevent many of the problems associated with pedals. Here are some tips:

• Regular Cleaning and Greasing: Remove and clean the pedals at least once a year, more often if you ride in wet or dirty conditions. Re-grease the threads before reinstalling them.
• Check for Loose Pedals: Periodically check that the pedals are securely tightened.
• Inspect Pedal Bearings: Inspect the pedal bearings for smooth rotation. If they feel rough or gritty, they may need lubrication or replacement. Some pedals have sealed bearings and cannot be serviced, requiring complete pedal replacement.
• Avoid Over-Tightening: Over-tightening pedals can damage the threads and make future removal difficult. Use a torque wrench to tighten the pedals to the manufacturer's recommended specification.

Conclusion

Installing and removing bicycle pedals is a fundamental skill for any cyclist. By understanding pedal thread orientation, using the right tools, and following the steps outlined in this guide, you can confidently tackle this task. Remember to prioritize safety, use proper technique, and be patient. With a little practice, you'll be able to maintain your pedals like a pro, ensuring smooth and efficient riding for years to come.
