How to Post-Process 3D Prints for High Strength

3D printing has revolutionized the way we approach manufacturing, prototyping, and even hobbyist activities. The ability to create intricate objects with relative ease is a major benefit, but one area where 3D printed parts often fall short is in their mechanical strength. While 3D prints can be incredibly detailed and complex, they sometimes lack the strength needed for functional use in demanding environments. Thankfully, with proper post-processing, it's possible to enhance the strength of your 3D prints significantly.

In this article, we'll explore a range of methods and techniques that can be employed after 3D printing to improve the strength of printed parts, including material choices, chemical treatments, thermal methods, and physical reinforcement techniques. The aim is to equip you with the knowledge needed to achieve high-strength 3D printed parts that can be used in functional applications.

Understanding the Basics of 3D Printing Strength

Before diving into post-processing techniques, it's important to understand why 3D prints sometimes lack the strength we expect. Several factors contribute to this issue:

• Layer adhesion: 3D prints are made by layering material on top of itself. The strength between these layers, called interlayer adhesion, can sometimes be weaker than the strength of the material itself, resulting in weak points in the printed part.
• Material properties: The type of filament used in 3D printing plays a major role in the strength of the print. Some materials are more suited to load-bearing applications than others. For instance, PLA is easy to print with but relatively weak compared to materials like ABS, Nylon, or carbon-fiber-infused filaments.
• Print settings: Factors such as layer height, infill density, and print speed can all affect the strength of the printed part. A low infill density or poorly calibrated machine settings can result in weaker prints.
• Print orientation: The direction in which a part is printed can significantly affect its strength. Parts printed vertically may be weaker along the Z-axis because of weaker layer adhesion.

Understanding these variables helps in identifying the most effective methods for improving strength after the print is completed.

Methods of Post-Processing to Improve 3D Print Strength

1. Annealing (Thermal Post-Processing)

Annealing is a heat treatment process that involves heating a 3D printed part to a specific temperature and holding it at that temperature for a period of time, then cooling it slowly. This process can improve the crystallinity of certain thermoplastic materials, leading to enhanced mechanical properties such as strength, stiffness, and heat resistance.

How Annealing Works

When certain thermoplastics are printed, they have an amorphous (non-crystalline) structure that can lead to weak points in the final product. By subjecting the print to controlled heat, the polymer chains align and crystallize, which improves interlayer bonding and the overall strength of the part.

Key Materials Suitable for Annealing:

• ABS: Commonly used for its strength and heat resistance, ABS can benefit significantly from annealing. The process makes ABS parts more stable and less prone to warping.
• Polycarbonate (PC): Known for its excellent strength and impact resistance, polycarbonate can be enhanced further through annealing.
• Nylon: This material exhibits better mechanical properties when annealed, especially in terms of heat resistance and tensile strength.

Annealing Process for 3D Prints:

1. Preheat the oven: Set your oven to the recommended annealing temperature for the material you are using (typically 80-120°C for ABS).
2. Place the print in the oven: Once the oven is preheated, place your 3D printed part inside. Ensure that the part is not in contact with any other materials that could cause it to deform or warp.
3. Maintain the temperature: Let the part sit at the annealing temperature for around 30 minutes to an hour, depending on the thickness and size of the part.
4. Cool down slowly: Allow the part to cool down slowly in the oven to avoid rapid cooling, which can cause warping or cracking.

2. Chemical Strengthening (Solvent Bonding)

Chemical strengthening involves using a solvent to dissolve the outer layer of the print, creating a smooth, hardened surface that is stronger and more durable. This is particularly effective with materials like ABS and ASA.

ABS Vapor Smoothing

A common method of chemical post-processing for ABS prints is vapor smoothing, using a solvent such as acetone. Acetone dissolves the surface layer of ABS, allowing it to reflow and form a smooth, glossy finish. The process not only improves the surface finish but can also help improve interlayer bonding, making the part stronger overall.

Steps for ABS Vapor Smoothing:

1. Prepare an acetone chamber: Use a sealed container (e.g., a glass jar or metal box) and place a small amount of acetone at the bottom. Ensure the acetone does not come in direct contact with the part.
2. Suspend the print inside: Place your print in the chamber, ensuring it is suspended above the acetone vapors.
3. Let the vapors work: Close the chamber and let the acetone vapors gently smooth the surface. Be careful not to leave the part in the chamber too long, as excessive exposure can cause distortion.
4. Allow to dry: Once the smoothing process is complete, remove the part and let it dry completely before handling.

Other Chemical Strengthening Methods:

• Epoxy coatings: Coating a 3D print with a layer of epoxy resin can provide additional strength and durability. The resin bonds to the surface of the print, enhancing both its structural integrity and resistance to moisture.
• Polyurethane coatings: Similar to epoxy, polyurethane coatings can be applied to enhance the strength and flexibility of a print, making it more resistant to wear and tear.

3. Surface Coatings and Reinforcements

In some cases, adding an external surface coating or reinforcement can increase the strength of a 3D print. These coatings can be applied manually and can provide additional protection against mechanical stresses, environmental factors, and wear.

Common Surface Coatings:

• Fiberglass: One of the most common materials used to reinforce 3D prints is fiberglass. By wrapping the print with layers of fiberglass cloth and then applying a resin to bind the layers, you create a much stronger and more rigid structure.
• Carbon fiber: Carbon fiber is extremely strong and lightweight, making it an excellent choice for reinforcing 3D printed parts. Carbon fiber-reinforced filament can also be used in the printing process itself, allowing the part to benefit from both the internal and external reinforcement.

Steps for Adding Surface Coatings:

1. Prepare the surface: Clean the 3D print thoroughly to ensure good adhesion of the coating material.
2. Apply the coating: Use a brush, roller, or spray to apply the fiberglass or carbon fiber material, depending on the method you're using.
3. Cure the resin: Once the coating is applied, allow the resin to cure according to the manufacturer's instructions. This will bond the reinforcement material to the print.
4. Sanding and finishing: After the resin has cured, sand the surface to achieve a smooth, professional finish.

4. Reinforced 3D Printing with Composite Materials

Using composite filaments in the printing process itself is a powerful way to enhance the strength of your 3D prints. Filaments infused with materials like carbon fiber, glass fiber, or metal powders offer significant improvements over standard thermoplastics.

Types of Reinforced Filaments:

• Carbon fiber reinforced filaments: These filaments are typically made by infusing carbon fibers into a base material like PLA, ABS, or Nylon. The result is a much stronger and stiffer part that is resistant to warping and environmental degradation.
• Glass fiber reinforced filaments: Glass fiber filaments provide enhanced tensile strength, making them ideal for parts that need to withstand heavy mechanical stress.
• Metal-filled filaments: Metal-filled filaments are a great option for those looking to combine the strength of metals with the ease of 3D printing. These filaments contain metal particles (e.g., copper, stainless steel) mixed with a thermoplastic base.

Benefits of Composite Filaments:

• Increased strength-to-weight ratio: The reinforcement materials provide added strength without adding significant weight.
• Improved thermal stability: Many composite filaments offer superior heat resistance compared to standard filaments.
• Enhanced durability: Composite materials tend to be more resistant to wear and tear, making them suitable for high-stress applications.

5. Post-Print Mechanical Reinforcement

Sometimes, after printing, you can further strengthen the part using mechanical reinforcement methods. These methods can add additional load-bearing capacity and further increase durability.

Techniques for Mechanical Reinforcement:

• Screws and bolts: Adding threaded inserts, screws, or bolts can reinforce 3D printed parts and make them capable of withstanding higher loads.
• Metal brackets: For larger structures or parts that require additional support, metal brackets can be attached to the printed part to improve strength and stability.

Steps for Adding Mechanical Reinforcements:

1. Determine the necessary reinforcements: Based on the intended use of the part, decide where and how reinforcements will be added.
2. Install inserts or brackets: Use tools like heat inserts for screws or bolts to embed metal fasteners into the print. Attach any necessary metal brackets.
3. Assemble the final part: After adding reinforcements, assemble the final part, ensuring everything is securely in place.

Conclusion

Post-processing plays a critical role in enhancing the strength and durability of 3D printed parts. By employing techniques such as annealing, chemical treatments, surface coatings, and using reinforced filaments, it's possible to create 3D prints that are capable of withstanding functional, real-world applications. Whether you're working on prototypes, end-use parts, or custom designs, improving the strength of your 3D prints ensures that they not only look great but perform well under stress.

With advancements in materials and techniques, 3D printing can now be used for a wider range of demanding applications, from automotive parts to medical devices. By integrating post-processing strategies into your workflow, you can unlock the full potential of your 3D printed creations, making them stronger, more durable, and more functional.
