How to Build a Simple Storage Bench

This guide provides a comprehensive, step-by-step approach to building a simple yet functional storage bench. Perfect for entryways, mudrooms, patios, or even as extra seating in your living room, this bench offers a convenient place to sit and store items like shoes, blankets, toys, or gardening tools. This project is suitable for intermediate DIYers with some experience in woodworking, though beginners with a careful approach and a willingness to learn can also successfully complete it. We'll cover everything from planning and materials selection to assembly and finishing, ensuring you have the knowledge and confidence to build a storage bench you'll be proud of.

Planning and Design

Before you start cutting wood, it's crucial to plan your storage bench. Consider the following factors:

• Location: Where will the bench be placed? This will influence the dimensions and style. Consider the available space and the existing decor. A bench for a narrow entryway will need different dimensions than one for a spacious patio.
• Dimensions: Determine the optimal length, width, and height. Common bench heights range from 16 to 20 inches. The width should be comfortable for sitting, typically between 14 and 18 inches. The length is the most flexible dimension and should be determined by the available space and storage needs.
• Storage Needs: What will you be storing inside the bench? This will impact the depth of the storage compartment and the type of lid or access you'll need. Will you be storing heavy items? Consider reinforcing the base and lid.
• Style: Do you prefer a modern, rustic, or traditional look? This will influence your choice of wood, hardware, and finishing techniques. Consider simple, clean lines for a modern look or distressed wood and wrought iron hardware for a rustic feel.
• Budget: How much are you willing to spend on materials? This will affect your choice of wood and hardware. Softwoods like pine are generally more affordable than hardwoods like oak or maple.

Once you have a good idea of your needs and preferences, create a simple sketch or diagram of your bench. This will help you visualize the final product and calculate the necessary materials. Include dimensions for all the components, such as the side panels, front panel, back panel, base, lid, and any internal supports.

Materials List

The following is a general materials list. Adjust quantities based on your specific bench dimensions and design.

• Wood:
  • For the side panels (2): ¾" thick plywood or solid wood (e.g., pine, poplar, oak) - Cut to your desired height and depth.
  • For the front and back panels (2): ¾" thick plywood or solid wood - Cut to your desired height and length.
  • For the base (1): ¾" thick plywood or solid wood - Cut to your desired length and depth.
  • For the lid (1): ¾" thick plywood or solid wood - Cut to your desired length and depth, with a slight overhang (about 1 inch) on all sides.
  • For internal supports (optional): 2x4 lumber or ¾" plywood - Cut to provide additional support for the base and lid, especially if storing heavy items.
  • For cleats (optional): ¾" thick wood strips - Used to attach the base to the side panels and provide additional support.
• Fasteners:
  • Wood screws (various lengths, e.g., 1 ¼", 1 5/8", 2 ½")
  • Wood glue
  • Finishing nails (optional, for attaching trim)
• Hardware:
  • Hinges (2 or 3, depending on the length of the lid)
  • Lid support (optional, to prevent the lid from slamming shut)
  • Handles or knobs (optional, for the lid)
  • Magnetic or spring-loaded latch (optional, to keep the lid closed)
• Finishing Supplies:
  • Wood filler (for filling nail holes and imperfections)
  • Sandpaper (various grits, e.g., 80, 120, 220)
  • Primer
  • Paint or stain
  • Sealer or polyurethane (for protection)
  • Rags or applicators for finishing

Wood Selection Considerations: Choose a wood that suits your budget, aesthetic preferences, and skill level. Pine is a readily available and affordable option, but it's relatively soft and prone to dents. Poplar is a good mid-range option, offering a smoother surface than pine. Hardwoods like oak, maple, and cherry are more durable and aesthetically pleasing but also more expensive and challenging to work with. Plywood offers excellent stability and is a good choice for the sides, base, and lid, especially if you plan to paint the bench.

Tools List

Having the right tools will make the project much easier and safer.

• Measuring tape
• Pencil
• Safety glasses
• Ear protection
• Saw (circular saw, miter saw, or hand saw)
• Drill with drill bits and screwdriver bits
• Sander (orbital sander or sanding block)
• Clamps
• Wood glue applicator (e.g., small brush or squeeze bottle)
• Hammer (if using finishing nails)
• Putty knife (for applying wood filler)
• Paintbrushes or spray gun (for finishing)
• Square

Tool Alternatives: If you don't have access to power tools, you can still complete this project using hand tools. A hand saw and hand plane can be used to cut and shape the wood. However, this will require more time and effort. Renting tools from a local hardware store is also a viable option.

Always wear safety glasses and ear protection when using power tools.

Step-by-Step Instructions

Step 1: Cut the Wood

Carefully measure and cut all the wood pieces according to your dimensions. Double-check your measurements before cutting to avoid errors. Use a saw to make precise cuts. If using a circular saw, use a straight edge and clamps to guide the saw for accurate cuts. For mitered corners (optional), use a miter saw to cut the pieces at a 45-degree angle. Label each piece as you cut it to avoid confusion later.

Step 2: Assemble the Box

Apply wood glue to the edges of the side panels and attach them to the front and back panels to form a rectangular box. Use clamps to hold the pieces together while the glue dries. Ensure the corners are square using a square tool. Once the glue is dry, reinforce the joints with wood screws. Predrill pilot holes for the screws to prevent the wood from splitting. Countersink the screws slightly to create a smooth surface for filling later.

Step 3: Attach the Base

There are several ways to attach the base to the box. One method is to use cleats. Attach the cleats to the inside of the side panels, front panel, and back panel, flush with the bottom edge. Apply wood glue and screw the cleats into place. Then, set the base on top of the cleats and secure it with screws. Alternatively, you can directly attach the base to the bottom edges of the box with glue and screws. Ensure the base is flush with the bottom of the box and that the screws are evenly spaced.

For added support, especially if storing heavy items, consider adding internal supports to the base. These can be made from 2x4 lumber or ¾" plywood and should be evenly spaced across the base. Attach the supports to the base and the side panels with glue and screws.

Step 4: Prepare the Lid

The lid should be slightly larger than the opening of the box to create an overhang. This helps to prevent the lid from sliding around and adds a finished look. If you're using plywood for the lid, you may want to consider adding edge banding to cover the exposed edges. Edge banding is a thin strip of wood or veneer that is applied to the edges of plywood to create a more finished look. You can attach edge banding with wood glue and an iron.

Step 5: Attach the Hinges

Position the hinges along the back edge of the box and the lid. Make sure the hinges are evenly spaced and aligned properly. Mark the screw holes and predrill pilot holes. Attach the hinges to the box and the lid with screws. Test the lid to make sure it opens and closes smoothly. If the lid doesn't align properly, adjust the hinges as needed.

Step 6: Add Lid Support (Optional)

A lid support prevents the lid from slamming shut and protects fingers. There are various types of lid supports available, such as friction hinges, gas struts, and chain supports. Choose a lid support that is appropriate for the size and weight of your lid. Install the lid support according to the manufacturer's instructions.

Step 7: Add Handles or Knobs (Optional)

Handles or knobs make it easier to open and close the lid. Choose handles or knobs that match the style of your bench. Position the handles or knobs on the lid and mark the screw holes. Predrill pilot holes and attach the handles or knobs with screws.

Step 8: Add a Latch (Optional)

A latch keeps the lid securely closed. There are various types of latches available, such as magnetic latches and spring-loaded latches. Choose a latch that is appropriate for your needs. Install the latch according to the manufacturer's instructions.

Step 9: Sand and Prepare for Finishing

Once the bench is assembled, it's time to sand the surfaces smooth. Start with a coarser grit sandpaper (e.g., 80 grit) to remove any imperfections, such as scratches or glue residue. Then, gradually move to finer grits (e.g., 120 grit, 220 grit) to create a smooth, even surface. Use a sanding block or orbital sander to ensure even sanding. Pay particular attention to the edges and corners.

After sanding, use wood filler to fill any nail holes, screw holes, or imperfections in the wood. Allow the wood filler to dry completely according to the manufacturer's instructions. Then, sand the wood filler smooth with fine-grit sandpaper.

Wipe down the entire bench with a tack cloth to remove any sanding dust. This will ensure a smooth and even finish.

Step 10: Finishing

Apply a coat of primer to the entire bench. Primer helps to seal the wood, prevent stains from bleeding through, and provide a better surface for the paint or stain to adhere to. Allow the primer to dry completely according to the manufacturer's instructions.

Choose your desired finish, such as paint or stain. If painting, apply two or three coats of paint, allowing each coat to dry completely before applying the next. If staining, apply the stain evenly with a brush or rag. Wipe off any excess stain after a few minutes. Allow the stain to dry completely according to the manufacturer's instructions.

Apply a coat of sealer or polyurethane to protect the finish and make the bench more durable. Sealer and polyurethane are available in various sheens, such as matte, satin, and gloss. Choose a sheen that suits your preferences. Apply the sealer or polyurethane evenly with a brush or rag. Allow the sealer or polyurethane to dry completely according to the manufacturer's instructions. You may need to apply multiple coats for added protection. Lightly sand between coats with fine-grit sandpaper to create a smooth finish.

Customization and Variations

The basic storage bench design can be customized in numerous ways to suit your specific needs and preferences. Here are a few ideas:

• Upholstered Lid: Add a layer of foam and fabric to the lid for a more comfortable seating surface. This is a great option if you plan to use the bench frequently for seating.
• Dividers: Install internal dividers to create separate compartments for storing different items.
• Drawers: Add drawers instead of a hinged lid for easier access to stored items. This will require more advanced woodworking skills.
• Slatted Design: Use slats instead of solid panels for a more rustic or modern look.
• Distressed Finish: Create a distressed finish by sanding away some of the paint or stain to reveal the wood underneath.
• Decorative Trim: Add decorative trim to the edges of the bench for a more polished look.
• Built-in Shoe Rack: Incorporate a shoe rack at the bottom of the bench for convenient shoe storage.

Safety Considerations

Safety should always be a top priority when working on DIY projects.

• Always wear safety glasses and ear protection when using power tools.
• Use a dust mask when sanding or working with wood.
• Work in a well-ventilated area when using paints, stains, or sealers.
• Read and follow the manufacturer's instructions for all tools and materials.
• Be careful when handling sharp objects, such as saws and knives.
• Keep your work area clean and organized.
• If you're not comfortable with a particular task, ask for help from a more experienced woodworker.

Conclusion

Building a simple storage bench is a rewarding DIY project that can add both functionality and style to your home. By following these step-by-step instructions and taking the time to plan your project carefully, you can create a storage bench that you'll be proud of for years to come. Remember to prioritize safety and don't be afraid to experiment with different customization options to make your bench truly unique. Happy building!
